16’x20’ Backyard BAR Pavilion Pergola Shade Structure Plans – DIY Blueprints, Step-by-Step Woodworking Guide (58 Pages)

sq ft320
Width16'
Depth20'
Outdoor bar 669

Elevation

click for gallery Reverse
plan

Plan

click for gallery Reverse
Outdoor bar 669

Plan Pricing from $40

Get Today's Discount Promo Code

    Total price: 0.00 $

    Width: 16'
    Depth: 20'
    sq ft: 320
    Units: Imperial Units
    House style: DIY Plans, Modern, New Plans
    Plan Type: Pavilion

    Backyard 16’x20’ BAR Pavilion Pergola Shade Structure Plans – DIY Blueprints, Step-by-Step Woodworking Guide, Instant PDF Download.



    Build your own 16’x20’ Bar | Pergola | Pavilion with these detailed (58-page) DIY woodworking plans! Whether you’re creating a cozy outdoor retreat, a backyard entertainment space, or a sturdy shelter for your patio, this step-by-step guide makes it easy to construct a professional-grade structure with clear instructions and precise measurements.



    🌟 Build Features:
    ■ Build Size: 16’x20’
    ■ Overall Height: 11’-5 5/16″
    ■ Foundation: Reinforced concrete for maximum stability
    ■ Roof Truss: 6×12 beams spaced 48″ O.C.
    ■ Roof Pitch: 5° for a modern, flat-roof aesthetic
    ■ Support Pillars: Heavy-duty 8×8 posts for superior strength
    ■ Beams: Sturdy 8×8 wood construction



    The plan is provided for personal use only and is copyrighted by BestHomesPlans.
    Commercial use or redistribution is strictly prohibited.



    Thank you and Good Luck)

    Material & Cut List
    Tools List
    Full 2D Plans
    Step-by-Step Instructions
    3D Diagrams
    Detailed Drawings
    Helpful Tips
